CS113: Algorithms & Object-Oriented Design

Algorithms and object-oriented design demonstrated across bathroom/, S3uploads/, groups/, and chat/.

Source: Pirna-spring (Spring backend) · Pirna-pages (frontend)

Course alignment

Learning Objective	Evidence Required	Assessment Method
Algorithms
Searching	Implement search algorithms (linear, binary, database queries)	Code review: Search functionality in API endpoints
Sorting	Apply practical sorting to data collections (by date, name, priority, score) using Comparator/Comparable	Code review: Comparator/Comparable implementations for business logic sorting
Hashing	Use hashing for passwords, data integrity, efficient lookups	Code review: BCrypt/hashing in authentication, HashMap usage
Algorithm Analysis	Analyze time/space complexity of implemented algorithms	Documentation: Big-O analysis in code comments or blog
Object-Oriented Design
Abstraction	Create abstract classes or interfaces to define contracts	Code review: Abstract base classes, interface definitions
Encapsulation	Use private fields with public getters/setters, hide implementation	Code review: Proper access modifiers in classes
Inheritance	Extend base classes to create specialized functionality	Code review: Class hierarchies (User -> Student/Teacher)
Polymorphism	Override methods, use interface implementations for flexible design	Code review: Method overriding, interface polymorphism
Design Patterns	Apply appropriate design patterns (MVC, Repository, Factory, Singleton)	Code review: Pattern usage in application architecture

Algorithms

Searching

Evidence required — Implement search algorithms (linear, binary, database queries).
Assessment — Code review: Search functionality in API endpoints.

This module implements linear search and database (JPA) queries. It does not implement binary search — the data is either unsorted in-memory (a comma-separated queue) or searched by the database engine, so neither path warrants a binary search. The honest evidence below is linear scanning plus delegated SQL queries.

Linear search over a queue. In BathroomQueue.java:73-78 the controller converts a comma-separated string into a list and uses indexOf() to perform a linear search, giving O(n) time complexity.

// BathroomQueue.java:73-78 (distilled)
import java.util.*;

public class Main {
    static String peopleQueue = "alice,bob,carol";

    static int getStudentIndex(String studentName) {
        if (peopleQueue == null || peopleQueue.isEmpty()) return -1;
        List<String> students = Arrays.asList(peopleQueue.split(","));
        return students.indexOf(studentName);   // O(n) linear scan
    }

    public static void main(String[] args) {
        System.out.println("index of bob:  " + getStudentIndex("bob"));
        System.out.println("index of dave: " + getStudentIndex("dave"));
    }
}

Database search with Spring Data JPA. In GroupsJpaRepository.java:46-50, findByName() performs an exact indexed lookup while the LIKE query supports partial matching — in both cases the search is delegated to the database engine.

Optional<Groups> findByName(String name);   // indexed exact lookup

@Query("""
SELECT g
FROM Groups g
WHERE LOWER(g.name) LIKE LOWER(CONCAT('%', :searchTerm, '%'))
ORDER BY g.name
""")
List<Groups> searchByName(@Param("searchTerm") String searchTerm);

S3 prefix search. In S3FileHandler.java:158-178 all S3 objects under a prefix are scanned (another linear scan), a common pattern for cloud file systems.

// S3FileHandler.java:158-178 (distilled — the prefix scan itself)
import java.util.*;
import java.util.stream.*;

public class Main {
    public static void main(String[] args) {
        // Stand-in for the bucket's object keys.
        List<String> allKeys = List.of(
            "uid1/photo.png", "uid1/notes.txt", "uid2/photo.png");
        String prefix = "uid1/";

        List<String> matches = allKeys.stream()
            .filter(key -> key.startsWith(prefix))
            .collect(Collectors.toList());

        System.out.println("keys under " + prefix + " -> " + matches);
    }
}

Sorting

Evidence required — Apply practical sorting to data collections (by date, name, priority, score) using Comparator/Comparable. Note: Merge, Selection, and Insertion are requirements in AP study sessions.
Assessment — Code review: Comparator/Comparable implementations for business logic sorting.

Java Comparator sorting. In GroupChatPresenceService.java:80-83 a comparator method reference performs case-insensitive sorting by name.

// GroupChatPresenceService.java:80-83 (distilled)
import java.util.*;
import java.util.stream.*;

public class Main {
    public static void main(String[] args) {
        Map<String, Integer> participantCounts = new LinkedHashMap<>();
        participantCounts.put("Bob", 2);
        participantCounts.put("alice", 5);
        participantCounts.put("Carol", 1);

        List<String> sorted = participantCounts.keySet().stream()
                .sorted(String::compareToIgnoreCase)
                .collect(Collectors.toList());

        System.out.println(sorted);
    }
}

Database sorting. In TeacherJpaRepository.java:9 and GroupsJpaRepository.java:17 the sorting is delegated to SQL ORDER BY, which is more efficient than in-memory sorting for large datasets.

List<Teacher> findAllByOrderByFirstnameAsc();
List<Groups>  findAllByOrderByNameAsc();

Hashing

Evidence required — Use hashing for passwords, data integrity, efficient lookups.
Assessment — Code review: BCrypt/hashing in authentication, HashMap usage.

This module does not implement BCrypt password hashing. The honest evidence here is HashMap usage — hash-based data structures (HashMap, ConcurrentHashMap) for O(1) lookups, plus deterministic content-addressed S3 keys for efficient retrieval.

HashMap analytics aggregation. In TinkleStatisticsService.java:40-47, hash-based key lookup gives average-case O(1) access while aggregating per-user durations.

// TinkleStatisticsService.java:40-47 (distilled)
import java.util.*;

public class Main {
    public static void main(String[] args) {
        Map<String, List<Long>> userWeeklyDurations = new HashMap<>();
        userWeeklyDurations.put("alice", List.of(30L, 50L));
        userWeeklyDurations.put("bob", List.of(45L, 20L, 25L));

        Map<String, Long> averageWeeklyDurations = new HashMap<>();

        for (Map.Entry<String, List<Long>> entry : userWeeklyDurations.entrySet()) {
            long total = entry.getValue()
                              .stream()
                              .mapToLong(Long::longValue)
                              .sum();

            averageWeeklyDurations.put(
                entry.getKey(),
                total / entry.getValue().size()   // hash-based O(1) put
            );
        }

        System.out.println(averageWeeklyDurations);
    }
}

Concurrent hash tables. In GroupChatPresenceService.java:23-24, thread-safe concurrent hashing via ConcurrentHashMap.merge() enables scalable multi-user chat presence tracking.

// GroupChatPresenceService.java:23-24 (distilled — thread-safe counting)
import java.util.concurrent.*;

public class Main {
    public static void main(String[] args) {
        ConcurrentMap<String, Integer> participantCounts = new ConcurrentHashMap<>();

        // merge() is an atomic read-modify-write — safe under concurrency.
        participantCounts.merge("groupA", 1, Integer::sum);
        participantCounts.merge("groupA", 1, Integer::sum);
        participantCounts.merge("groupB", 1, Integer::sum);

        System.out.println(participantCounts);   // {groupA=2, groupB=1}
    }
}

S3 content key hashing. In S3FileHandler.java:199-201, deterministic content-addressed keys are generated for efficient object retrieval.

// S3FileHandler.java:199-201 (distilled)
public class Main {
    static String generateKey(String uid, String filename) {
        return uid + "/" + filename;
    }

    public static void main(String[] args) {
        System.out.println(generateKey("uid42", "photo.png"));
        System.out.println(generateKey("uid42", "notes.txt"));
    }
}

Algorithm Analysis

Evidence required — Analyze time/space complexity of implemented algorithms.
Assessment — Documentation: Big-O analysis in code comments or blog.

Operation	File	Big-O
`addStudent` (string append)	`BathroomQueue.java:53`	`O(n)` string copy
`getFrontStudent`	`BathroomQueue.java:115`	`O(n)` split
`getStudentIndex`	`BathroomQueue.java:73`	`O(n)` linear scan
`joinGroup / leaveGroup`	`GroupChatPresenceService.java:26`	`O(1)` average
`getMessages` JSONL replay	`GroupChatService.java:54`	`O(n)`
`deleteMessage`	`GroupChatService.java:107`	`O(n)` read + `O(n)` write
`deleteFiles`	`S3FileHandler.java:118`	`O(n)` list
`calculateAverageWeeklyDurations`	`TinkleStatisticsService.java:27`	`O(n·k)`

Trade-off note. The chat write path is O(n) per message because addMessage() re-serializes and re-uploads the entire JSONL file. This works for small groups but scales poorly as message count increases.

Object-Oriented Design

Abstraction

Evidence required — Create abstract classes or interfaces to define contracts.
Assessment — Code review: Abstract base classes, interface definitions.

FileHandler interface. In FileHandler.java:1-47 a storage abstraction layer decouples controllers from storage implementation details — controllers depend on the interface, not on a concrete store.

// FileHandler.java (distilled — abstraction in action)
public class Main {
    // The abstraction: controllers depend on this, not on a concrete store.
    interface FileHandler {
        String uploadFile(String base64Data, String filename, String uid);
        boolean fileExists(String uid, String filename);
    }

    // One concrete implementation behind the interface.
    static class LocalFileHandler implements FileHandler {
        public String uploadFile(String base64Data, String filename, String uid) {
            return "stored " + filename + " for " + uid
                    + " (" + base64Data.length() + " chars)";
        }
        public boolean fileExists(String uid, String filename) {
            return true;
        }
    }

    public static void main(String[] args) {
        FileHandler handler = new LocalFileHandler();   // decoupled from impl
        System.out.println(handler.uploadFile("aGVsbG8=", "note.txt", "uid1"));
        System.out.println("exists? " + handler.fileExists("uid1", "note.txt"));
    }
}

Abstract base class. In Submitter.java:26-42 an abstract base class provides shared functionality for Groups and Person, demonstrating abstraction through an abstract base class.

public abstract class Submitter {

    @Id
    @GeneratedValue
    private Long id;

    @OneToMany(mappedBy = "submitter", ...)
    private List<AssignmentSubmission> submissions;

    public List<Person> getMembers() {
        if (this instanceof Groups)
            return ((Groups) this).getGroupMembers();

        return List.of((Person) this);
    }
}

Encapsulation

Evidence required — Use private fields with public getters/setters, hide implementation.
Assessment — Code review: Proper access modifiers in classes.

In BathroomQueue.java:27-32 and 53-110, internal state is hidden with private and the public methods (addStudent, approveStudent, getAway) are the only access path. Domain methods enforce invariants and prevent invalid state changes — for example, approveStudent() ensures away <= maxOccupancy.

// BathroomQueue.java:27-110 (distilled — private state + invariant)
public class Main {
    static class BathroomQueue {
        private String peopleQueue = "";
        private int away = 0;
        private int maxOccupancy = 1;

        public void addStudent(String studentName) {
            peopleQueue = peopleQueue.isEmpty() ? studentName : peopleQueue + "," + studentName;
        }

        public void approveStudent() {
            if (away < maxOccupancy) away++;   // invariant: away <= maxOccupancy
        }

        public int getAway() { return away; }
    }

    public static void main(String[] args) {
        BathroomQueue q = new BathroomQueue();
        q.addStudent("alice");
        q.addStudent("bob");

        q.approveStudent();
        q.approveStudent();   // blocked — maxOccupancy already reached

        System.out.println("away = " + q.getAway() + " (capped at maxOccupancy)");
    }
}

Inheritance

Evidence required — Extend base classes to create specialized functionality.
Assessment — Code review: Class hierarchies (User -> Student/Teacher).

In this project the hierarchy is Submitter -> Groups / Submitter -> Person. In Groups.java:29-46, Groups inherits fields and behavior from Submitter and adds specialized membership functionality.

// Groups.java:29-46 (distilled — inheritance without the JPA annotations)
import java.util.*;

public class Main {
    static abstract class Submitter {
        Long id;
        String describe() { return "Submitter#" + id; }
    }

    static class Groups extends Submitter {
        private List<String> groupMembers = new ArrayList<>();
        private String name, period, course;

        Groups(String name) { this.name = name; }
        void addMember(String p) { groupMembers.add(p); }
        @Override String describe() { return name + " " + groupMembers; }
    }

    public static void main(String[] args) {
        Groups g = new Groups("Period 3 CS");
        g.id = 7L;                       // field inherited from Submitter
        g.addMember("alice");
        g.addMember("bob");
        System.out.println(g.describe());
    }
}

JOINED inheritance strategy. In Submitter.java:17 the @Inheritance(strategy = InheritanceType.JOINED) annotation gives parent and child classes their own tables, joined relationally through shared IDs.

@Inheritance(strategy = InheritanceType.JOINED)

Polymorphism

Evidence required — Override methods, use interface implementations for flexible design.
Assessment — Code review: Method overriding, interface polymorphism.

FileHandler polymorphism. In ChatService.java:25 and GroupChatService.java:28 the dependency could be typed as FileHandler, so any implementation (S3FileHandler, LocalFileHandler) could be injected.

private final S3FileHandler s3FileHandler;

s3FileHandler.uploadFile(base64Data, MESSAGES_FILE, groupName);

Runtime behavior switching. In Submitter.java:36-41, behavior changes based on the runtime subtype.

// Submitter.java:36-41 (distilled — runtime dispatch)
import java.util.*;

public class Main {
    static abstract class Submitter {
        List<String> getMembers() {
            if (this instanceof Groups)
                return ((Groups) this).groupMembers;
            return List.of(((Person) this).name);
        }
    }
    static class Groups extends Submitter { List<String> groupMembers = new ArrayList<>(); }
    static class Person extends Submitter { String name; Person(String n) { name = n; } }

    public static void main(String[] args) {
        Groups g = new Groups();
        g.groupMembers.addAll(List.of("alice", "bob"));

        Submitter asGroup = g;                 // same static type...
        Submitter asPerson = new Person("carol");

        System.out.println("group  -> " + asGroup.getMembers());   // [alice, bob]
        System.out.println("person -> " + asPerson.getMembers());  // [carol]
    }
}

Design Patterns

Evidence required — Apply appropriate design patterns (MVC, Repository, Factory, Singleton).
Assessment — Code review: Pattern usage in application architecture.

MVC pattern. The bathroom module separates the three roles cleanly, and the same split appears in the groups module: the Model is BathroomQueue, the View is BathroomViewController, and the Controller is BathroomQueueApiController.

Repository pattern. Database access logic is encapsulated behind repository interfaces such as BathroomQueueJPARepository.java and GroupsJpaRepository.java.

Strategy / dependency injection. Injecting @Autowired private FileHandler fileHandler; allows interchangeable storage implementations to be swapped in without changing the consumer.

Singleton pattern. Spring-managed @Service beans are singletons by default — for example HallPassService, GroupChatService, TinkleStatisticsService, and S3FileHandler.

DTO pattern. Data transfer objects such as QueueAddReq, QueueDto, GroupCreateDto, BulkGroupCreateDto, and FileUploadRequest carry request and response data across boundaries.

Factory pattern. Static methods like BathroomQueue.init() generate preconfigured objects.

// BathroomQueue.init() (distilled — static factory method)
public class Main {
    static class BathroomQueue {
        String teacherEmail;
        String peopleQueue;

        static BathroomQueue init() {                // factory
            BathroomQueue q = new BathroomQueue();
            q.teacherEmail = "default@school.edu";
            q.peopleQueue = "";                      // preconfigured empty line
            return q;
        }
    }

    public static void main(String[] args) {
        BathroomQueue q = BathroomQueue.init();
        System.out.println("preconfigured queue for " + q.teacherEmail);
    }
}
